KERN ITB User Manual

Settings in the menuITB-BA-e-0720
25User manual ME-Nr. 22017071 01/07
3.6 Configuring interfaces (COMMUNICATION)
3.6.1 COM1/COM2 -> MODE – operating mode of the serial interface
3.6.2 COM1/COM2 -> PRINTER – settings for protocol printout
This menu item only appears if the mode "Print" or "A.Print" is selected.
3.6.3 COM1/COM2 -> PARAMET – communication parameter
Print Manual data output to the printer with
A.Print Automatic output of stable results to the printer (e. g. for series weighing operations)
CONtINU Ongoing output of all weight values via the interface
dIALOG Bi-directional communication via MT-SICS commands, control of the scale via PC
CONt.OLd As per CONtINU, see above, but with 2 fixed blanks in front of the unit (compatible
with Spider 1/2/3)
dIAL.OLd As per dIALOG, see above, but with 2 fixed blanks in front of the unit (compatible
with Spider 1/2/3)
dt-b DigiTOL-compatible format.
GROSS
• Transfer of the gross weight, identified with "G"
tArE
• Transfer of the tare weight
nEt
• Transfer of the net weight
dt-G As per dt-b, see above, gross weight identified with "G"
COnt-Wt TOLEDO Continuous mode
2nd.dISP For connecting a second display (automatically activates the 5-V voltage supply at
Pin 9)
tEmPLat Selecting protocol printout
StdArd
• Standard printout
tEmPLt1
• Printout in accordance with Template 1
tEmPLt2
• Printout in accordance with Template 2
ASCi.FmtT Selecting formats for the protocol printout
LINE.Fmt
• Line format: MULtI (multi-line) or SINGLE (single-line)
LENGtH
• Line length: 0 ... 100 characters, appears only with line format MULtI
SEPArAt
• Separator: , ; . / \ _ and space; appears only with line format SINGLE
Add LF
• Line feed: 0 ... 9
bAUd Selecting baud rate: 300, 600, 1200, 2400, 4800, 9600, 19200, 38400 baud
PAritY Selecting parity: 7 none, 8 none, 7 odd, 8 odd, 7 even, 8 even
H.SHAKE Selecting Handshake: NO, XONXOFF
