Technical data and accessories

User manual ME-Nr. 22017071 01/07

6.1.3 Net weights

6.1.4 Interface connections

The compact scale can be fitted with a maximum of 2 interfaces. The following com-

binations are possible:

6.1.5 Assignment of the interface connections

without battery with OptionPac

(incl. battery)

ITB 2.4 kg 4.4 kg

COM1 COM2 Note

RS232 –

RS232 RS232

RS232 Ethernet

Pin RS232

(COM1/COM2)

1–

2 TxD1/2

3 RxD1/2

4–

5 GND

6–

7–

8–

9VCC
