14.4. Data output

14.4.1. Format for data transmission

Any of the data formats below may be set by selecting the relevant function on the

balance ( see menu overview chpt. 7.2):

6-digit data format

Consisting of 14 words, including final character; CR=0DH, LF=0AH (CR=balance

reverse motion / LF=line feed)

7-digit data format

NOTE: The 7-digit format is identical to the 6-digit, with the exception of the addi-

tional character D8.

Extended 7-digit data format

Not documented

14.4.2. Signs

P 1 = 1 word

Code

Meaning

2 B H

Data is 0 or positive

2 D H

Data is negative

14.4.3. Data

6-digit data format (D1-D7): 7 words

7-digit data format (D1-D8): 8 words

D1-D7, D8, D9

Code

Meaning

0 - 9

30 H – 39 H

Data 0 to 9 (max. 6 characters in 6-digit format)

2 EH

Decimal point, position not fixed

20 H

Space character, leading cero suppressed

2 FH

Slash "/" is inserted after the e-value.

KERN PES 620-3M Operating Instruction
