Steps for Using the Puncturer
1
4
1. Unscrew and remove the puncturer’s
adjustable tip.
2. Insert a lancet into the carrier.
3. Twist off the protective cover.
4. Replace the adjustable tip tightly.
Choose a desired skin penetration
depth by rotating the top portion of the
adjustable tip until the setting number
lines up to the arrow. Settings are
based on skin type:
Depth 1~2: for soft or thin skin
Depth 3: for average skin
Depth 4~5: for thick or calloused skin
5. Hold the tip of the puncturer with one
hand and pull the sliding barrel with
the other hand. When a click is felt, the
trigger rises up. Release the sliding
barrel, it will move back to its original
position.
2
5-1
3
5-2
23
