Kewtech KT72

19
6.2 Class ll Test
The Class ll appliances have the indication of DOUBLE INSULATION
or the

symbol. The class ll insulation test is to check the insulation
resistance and leakage current of the appliances is within the range
defined in the standards.
Measuring
method
Switch ON the power.
Set the function switch to
the Class II position.
Fig.13
