14
EN
CT-400
• Single-phase or three phase control unit for 1 motor 400/230V up to 2Hp with electrical
obstacle detection
• For sliding gates or foll-up doors.
• Electrical obstacle detection, interior/exterior brake , 4 functions, radio decode supplied.
Manuals for the installer
U
V
Line 230/400 Vac
Line 230/400 Vac
T
SPY
SPY
-7-
-6-
-5-
-4-
-3-
-2-
Selection of the 400 Vac power supply
Selection of the 230 Vac power supply
Selection of the power supply
-10-
-9-
-8-
Signal light or interior brake
Opening Limit Switch
Closing Limit Switch
Stop
Open
-21-
-20-
-19-
-18-
-17-
-16-
-15-
-13-
W
-11-
-22-
-23-
-24-
-25-
-27-
Close
START
PEDESTRIAN
Mechanical edge NC
-1-
-12-
T
-26-
-28-
Line 230/400 Vac
Signal light or interior brake
-29-
-30-
24 Vac
24 Vac
COM
COM
Common
Common
-14-
Photo-test
Photo-test
FTS
FTS
N.C.
N.O. N.O. N.O. N.O.
M
Three-phase motor (400V) or
single-phase motor ( 230V)
Up 80W
TX
RX
*
*
Connect this point to the FTS terminal board
for the photo-test otherwise connect it to the
24V terminal board.
**
**
Connect to the 24V terminal board for test
OUT2
OUT2
GND
ANT
+ Antenna
- Antenna
Output for isolated contact of the 2nd channel
Output for isolated contact of the 2nd channel
12 vac Output (up 1A)
12 vac Output (up 1A)
12VAC
12VAC
.
CLOSE
command
Control board dispose of
2 buttons for opening and
closing of the door.
See page no.4
OPEN
command
