5
EN
2 - PRODUCT INTRODUCTION
2.1 - Product description
2.2 - Composition
2.3 - Models and technical characteristics
Halo is an irreversible electromechanical gearmotor suitable for
automating overhead doors up to 14m
2
and sectional doors up to
16m
2
. Halo is equipped with an encoder, a control unit and an inte-
grated 4-channel receiver. The rail is pre-assembled with a belt, in
one piece or 3 pieces.
A special aluminium rail, powder coated and with integrated LEDs,
The automation system for garage doors is contained in two boxes
forming the automation system’s and the rail system’s packaging:
allows for garage lighting both during movement and at any other
time.
The special at design of the motor housing also makes it possible
to install it less invasively near the door cross beam or the spring
holder shaft.
CODE DESCRIPTION POWER
900HA7
For sectional doors up to 10 sqm (with 3 m rail) or 11 sqm (with 4 m rail), a 24 Vdc motor and a
control unit with an integrated receiver and 230Vac power supply
700N
900HA10
For sectional doors up to 13 sqm (with 3 m rail) or 16 sqm (with 4 m rail), a 24 Vdc motor and a
control unit with an integrated receiver and 230Vac power supply
1000N
900HA10E
For sectional doors up to 13 sqm (with 3 m rail) or 16 sqm (with 4 m rail), "Low Energy" with 24 Vdc
motor and a control unit with an integrated receiver and 230Vac power supply
1000N
900HA10L
For sectional doors up to 13 sqm (with 3 m rail) or 16 sqm (with 4 m rail), a 24 Vdc motor and a
control unit with an integrated receiver and 120Vac power supply
1000N
HEAD/RAIL COMPATIBILITY
HA7 HA10 - HA10E - HA10L
900RAB3 X X
900RAB3X1 X X
900RAB4 X X
900RAB6 X
900RAL30 X
900RAL40 X
TECHNICAL SPECIFICATIONS 900HA7 900HA10 900HA10E 900HA10L
Speed 12 cm/s 12 cm/s 12 cm/s 12 cm/s
Force 700 N 1000 N 1000 N 1000 N
Max cycles/hour
(1)
20 20 20 20
Max consecutive cycles/hour
(1)
10 10 10 10
Rated power 80W 100W 100W 100W
Stand-by power 5,5 W 5,5 W <0,5 W 5,5 W
Power supply
230Vac (±10%)
50Hz
230Vac (±10%)
50Hz
230Vac (±10%)
50Hz
120Vac (±10%)
50/60Hz
Flashing 3 W MAX 3 W MAX 3 W MAX 3 W MAX
Courtesy light on rail with integrated LEDs - 20 W MAX 20 W MAX 20 W MAX
Accessories power output
100mA (24 Vdc NOT
REGULATED)
100mA (24 Vdc NOT
REGULATED)
100mA (24 Vdc NOT
REGULATED)
100mA (24 Vdc NOT
REGULATED)
Fuse 1 power line 1AT 1AT 1AT 2AT
Max no. of transmitters that can be stored
ROLLING CODE
90 90 90 90
Degree of protection IP 20 IP 20 IP 20 IP 20
Use in highly acid, saline or explosive
atmosphere
NO NO NO NO
Dimensions (L x D x H): 235-330-84 mm 235-330-84 mm 235-330-84 mm 235-330-84 mm
Weight 6,7 Kg 6,7 Kg 6,7 Kg 6,7 Kg
Working temperature -10°C/+45°C -10°C/+45°C -10°C/+45°C -10°C/+45°C
Maximum door size 11 m
2
16 m
2
16 m
2
16 m
2
Maximum door weight 90 Kg 130 Kg 130 Kg 130 Kg
(1)
for door up to 2m in height
FIG. 1 head package contents with parts list
FIG. 2 LED rail
FIG. 3 single piece steel rail
FIG. 4 3-piece steel rail
