Key-Disp KD31M - Product Name and Model; Specifications; Appearance and Size

1
Product name and model
Intelligent digital display of eBike, model: KD31M.
Specifications
●24V/36V /48V Power Supply
●Rated working current: 10mA
●The maximum working current: 30mA
●Off leakage current: <1uA
●The supply controller working current: 50mA
●Operating temperature: -20 ~ 60 ℃
●Storage temperature: -30 ~ 70 ℃
Appearance and Size
Display appearance and dimension figure (unit: mm)
