Function Summary
KD31M can provide a lot of functions to fit the users’ needs. The indicating contents are as following:
●Smart Battery Indication
●Assistance-level Indication
●Running Speed Indication
●Trip distance and total distance
●The push-assistance function
●The Lighting On/Off
●Error Code indication
●Various Parameters Settings (e.g. wheel size, PAS level, etc.)
●Recover Default Setting
Button Definition
There are three buttons ( , , ) on the KD31M display that represent the following functions
respectively MODE, UP, DOWN.
Monitor Area
Monitor Area
General Operation
◆Switching the eBike System On/Off
To switch on the eBike system, hold the MODE button for 2 s.
In the same way to hold MODE button for 2 s again, the eBike system will be switched off.
When switching off the eBike system, the leakage current is less than 1 uA.
■
When parking the eBike for more than 10 minutes, the eBike system switches off automatically.
◆
Displaying Interface
The display consists four displaying state interfaces, respectively is the Running Speed, Battery
percentage, Trip distance and Total distance, the default value is Running Speed.
When the eBike is parked, briefly press the MODE button, the display can in turn circular display Battery
percentage, Trip distance and Total distance, every state displays 2 s and then automatically returns to the
Running Speed interface.
When the eBike is riding, press the MODE button, the display can in turn circular display Battery
percentage and Trip distance, every state displays 2 s and then automatically returns to the Running Speed
interface.
◆Switching Push-assistance mode On/Off
To access the push-assistance mode, hold the DOWN button for 2 s, the eBike will go on at a uniform
speed of 6 Km/h, “P” is showed on the screen at the same time. The push-assistance function switches off
as soon as you release the DOWN button.
Push-assistance mode
