Keysight Technologies 34980A

Calibration Procedures 3
Keysight 34980A Service Guide 45
Input
Quick
Check
Error from Nominal
Function
[1]
Range 24 hour 90 day 1 year
100 mV
DC Volts
100 mV ± 6.5 µV ± 8 µV ± 9 µV
1 V 1 V ± 26 µV ± 37 µV ± 47 µV
10 V 10 V Q ± 190 µV ± 250 µV ± 400 µV
100 V 100 V Q ± 2.6 mV ± 4.1 mV ± 5.1 mV
300 V 300 V ± 12 mV ± 19.5 mV ± 22.5 mV
100 Ω
2-Wire
Ohms
[2]
and
4-Wire Ohms
100 Ω ± 6.5 mΩ ± 12 mΩ ± 14 mΩ
1 kΩ 1 kΩ Q ± 26 mΩ ± 90 mΩ ± 110 mΩ
10 kΩ 10 kΩ ± 250 mΩ ± 900 mΩ ± 1.1 Ω
100 kΩ 100 kΩ ± 2.5 Ω ± 9 Ω ± 11 Ω
1 MΩ 1 MΩ ± 30 Ω ± 90 Ω ± 110 Ω
10 MΩ 10 MΩ Q ± 1.6 kΩ ± 2.1 kΩ ± 4.1 kΩ
100 MΩ
[3]
100 MΩ ± 310 kΩ ± 810 kΩ ± 810 kΩ
10 mA
DC Current
10 mA ± 1.5 µA ± 5 µA ± 7 µA
100 mA 100 mA Q ± 14 µA ± 35 µA ± 55 µA
1 A 1 A ± 560 µA ± 900 µA ± 1.1 mA
[1] Select 6 ½ digit resolution.
[2] The 2-wire ohms resistance verification test is optional (see “Gain Adjustment Considerations” on page 51). For 2-wire ohms using a
multiplexer for the input connections, an additional 4 Ω of error for the relay contacts must be added. Add a 1-second channel delay when
using Fluke 5700 in 2-wire compensated mode. This avoids response time issues with 2-wire compensation when 34980A’s current source
contains a pulse.
[3] Verify only, no adjustment required.
Q: Quick performance verification test points.
