To return the instrument to an idle state before completing all waveform sourcing,
perform the following procedure.
15) If you are not on the top Function menu, press repeatedly until you are
back at the top level.
16) Press , , , and then press to make the instrument
return to the idle state.
At the top level of the Function menu
No tree structure is visible
A tree structure is visible
At a lower level in the Function menu
(1) Press Trigger
(2) Press Abort
(3) Press Trans.
(4) Press Ch 1
22 | Keysight | Sourcing Precise Current/Voltage Sinusoidal Waveforms Using the B2961A/62A – Demo Guide
Keysight B2900 Precision
Instrument Family
The B2900A series is a member of the
B2900 Precision Instrument Family,
which includes several different
source and measurement solutions.
Further information is available at
www.keysight.com/nd/b2900a
