1 Specifications
20 Keysight E3633A and E3634A Service Guide
Supplemental Characteristics
Remote sensing capability
Temperature coefficient, ±(% of output + offset)
Maximum change in output/readback per °C after a 30-minute warm-up
Table 1-2 Supplemental Characteristics
Parameter Keysight E3633A Keysight E3634A
Output Programming Range
(maximum programmable values)
Low Range
0 to +8.24 V/
0 to 20.6 A
0 to +25.75 V/
0 to 7.21 A
High Range
0 to +20.6 V/
0 to 10.3 A
0 to +51.5V/
0 to 4.12 A
OVP 1 V to 22 V 1 V to 55 V
Voltage Programming Speed:
Maximum time required for output
voltage to settle within 1% of its total
excursion (for resistive load). Excludes
command processing time.
OCP 0 A to 22 A 0 A to 7.5 A
Full Load No Load Full Load No Load
Up 95 msec 45 msec 80 msec 100 msec
Down 30 msec 450 msec 30 msec 450 msec
Voltage drop Up to 0.7 V per each lead
Load regulation
Add 5 mV to spec for each 1-volt change in the + output lead due to load
current changes
Load Voltage Subtract voltage drop in load leads from specified output voltage rating.
Voltage 0.01% + 3 mV
Current 0.02% + 3 mA
