Keysight Technologies E3633A - CC Performance Test Records

3 Calibration Procedures
72 Keysight E3633A and E3634A Service Guide
CC performance test records
Test Description Models
Actual
Result
Specifications
Upper Limit Lower Limit
CC Programming Accuracy @ 0
amps (IO)
Both +0.0100 A -0.0100 A
CC Readback Accuracy @ 0 amps Both
I
O
+ 0.0050 A I
O
- 0.0050 A
CC Programming Accuracy @ Full
Scale (IO)
(E3633A) 20.0500 A 19.9500 A
(E3634A) 7.0230 A 6.9770 A
CV Readback Accuracy @ Full
Scale
(E3633A)
I
O
+ 0.0350 A I
O
- 0.0350 A
(E3634A)
I
O
+ 0.0155 A I
O
- 0.0155 A
CC Load Effect (Load Regulation)
Maximum change: < (2.25 mA)
[a]
or (0.95 mA)
[b]
[a] For Keysight E3633A Model
[b] For Keysight E3634A Model
CC Source Effect (Line Regulation)
Maximum change: < (2.25 mA)
[a]
or (0.95 mA)
[b]
CC PARD (Normal mode) Both < 2 mA rms
CC PARD (Common mode) Both
< 1.5
μ A rms
