2Quick Start
40 Keysight E3633A and E3634A Service Guide
4 Save the operating state.
The operating state is now stored. To recall the stored state, go to the
following steps.
5 Turn on the recall mode.
Memory location “1” will be displayed in the recall mode.
This message appears on the display for approximately 3 seconds.
6 Recall the stored operating state.
Turn the knob to the right to change the displayed storage location to 3.
If this setting is not followed within 3 seconds with key stroke, the power
supply returns to normal operating mode and will not recall the instrument
state 3 from memory.
7 Restore the operating state.
The power supply should now be configured in the same state as when you
stored the state on the previous steps.
This message appears on the display for approximately 1 second.
DONE
RECALL 1
RECALL 3
DONE
