Characteristic and Specifications 7
E364xA User’s and Service Guide 193
Programming resolution Voltage <5 mV
Current <1 mA
Readback resolution Voltage <2 mV
Current <1 mA
Front panel resolution Voltage 10 mV
Current 1 mV
Transient response time <50 µs for the output to recover to within 15 mV following a change in the
output current from full load to half load or vice versa.
Settling time <90 ms for the output voltage to change from 1% to 99% or vice versa
following the receipt of the
VOLTage
or
APPLy
command via direct GPIB or
RS-232 interface.
[a] Accuracy specifications after a 1-hour warm-up period with no load and calibration at 25 °C.
[b] Meter accuracy specification at a minimum of 10 mV decimal limited by the front panel resolution.
Table 7-2 Electrical specifications
