Keysight Technologies E3649A

1 Getting Started
42 E364xA User’s and Service Guide
Rear panel
Figure 1-5 Rear panel
Table 1-5 Rear panel overview
No Description
1AC inlet
2 Power-line fuse-holder assembly
3 Power-line module
4 Output 1 rear output terminals
5 Output 2 rear output terminals
6 GPIB (IEEE-488) interface connector
7 RS-232 interface connector
