78 Keysight FieldFox Handheld Analyzers Service Guide
Theory of Operation
Operation in Modes
5-
Operation in Modes
The FieldFox User’s Guide describes the various modes of operation and
describes the user interface for each mode. The following information
describes how the hardware is used in the various modes to make
measurements.
There are seven basic modes of operation:
— CAT/TDR - Cable and Antenna Test
— NA - Network Analyzer
— SA - Spectrum Analyzer
— VVM - Vector Voltmeter
— PM - Power Meter (USB Sensor)
— CPM - Channel Power Meter
— ERTA - Extended Range Transmission Analysis
CAT, NA, and VVM modes have similar capabilities but are separate modes of
operation.
The basic modes listed above represent how the hardware may be used to
make basic measurements.
Additional modes will provide customized user interfaces but will not change
how the basic measurements are performed.
The following table indicates various modes in FieldFox analyzers and the
option dependencies. See the “Service Related User Operations” section of
Chapter 8 for more details.
Modes CAT/TDR NA SA VVM Power Meter
(USB Sensor)
Power Meter
(Built In)
Standard Option 210 Option 210 Option 210 Option 210 Option 210
CAT Measure Distance To
Fault (dB)
Return Loss &
DTF
Return Loss
(dB)
VSWR DTF (VSWR) More
Standard
Cable Loss
(1-Port)
Insertion Loss
(2-Port)
DTF
(Lin)
TDR
(Lin rho)
TDR
(ohm)
TDR
& DTF
Standard Option 210 Standard Option 215 Option 215 Option 215
NA
Measure
S11 S21 S12 S22 Format
(Log Mag)
Option 210 Option 211 Standard
