Keysight FieldFox Handheld Analyzers Service Guide 93
Replaceable Parts
Replaceable Parts Listings
Front Panel Group
1
Refer to Figure 6-2 for part locations.
1. Each time the FieldFox case is opened for any reason, you must order a Repair and Re-assembly Kit. See
“Miscellaneous Parts” on page 103.
Reference
Designator
Part Number Qty Description
Replacement Assemblies
A3 Front Panel Board
Assembly
N9927-60110 1 Front Panel Board Assembly—Includes:
A3 front panel interface board
Separately Replaceable Individual Parts and Assemblies
A1 N9912-40001 1 Keypad assembly
A2 N9927-60118 1 LCD assembly, 6.5-inch TFT VGA
W11 N9927-60007 1 Cable, A2 LCD to A5 System board
W13 N9927-60005 1 Cable, A2 LCD to A3 Front Panel Interface board
W14 N9927-60009 1 Cable, ribbon, A3 Front Panel Interface board to A5 System board
(1) 1000-1485 1 LCD lens filter
(2) N9927-60011 1 LCD Bracket assembly
(model numbers N991xA, N992xA, N993xA)
N9927-60029 1 LCD Bracket assembly
(model numbers N995xA, N996xA)
(3) 0515-1946 13 Screw, machine, 90-deg flat head, Torx T10, M3.0 x 6 mm
(4) 1990-3613 1 RPG (Rotary Pulse Generator). Includes cable W12, nut, and washer.
(5) W1312-40066 1 RPG knob
To Next Page
