Keysight InfiniiVision 3000 X-Series Oscilloscopes User's Guide 43

Learn the Rear Panel Connectors

For the following figure, refer to the numbered descriptions in the table that

follows.

Language 2 Channel Overlay 4 Channel Overlay

French 75019-94324 75019-94316

German 75019-94326 75019-94318

Italian 75019-94323 75019-94331

Japanese 75019-94311 75019-94312

Korean 75019-94329 75019-94321

Polish 75019-94335 75019-94334

Portuguese 75019-94327 75019-94319

Russian 75019-94322 75019-94315

Simplified Chinese 75019-94328 75019-94320

Spanish 75019-94325 75019-94317

Thai 75019-94333 75019-94332

Traditional Chinese 75019-94330 75019-94310
