Multi-Channel Antenna Calibration (MAC) Introduction
Product specifications & characteristics
Keysight Y1299A-003 MAC Reference Solution Startup Guide 15
E8257D PSG analog signal generator
20, 31.8, 40, 50 or 67 GHz
+26 dBm output power at 20 GHz
-143 dBc/Hz phase noise, typical (1 GHz signal)
The Keysight E8257D is a fully synthesized signal generator with high output
power, low phase noise, and optional ramp sweep capability.
Specifications apply over a 0 to 55 °C range, unless otherwise stated, and apply
after a 45 minute warm-up time. Supplemental characteristics, denoted as
typical, nominal, or measured, provide additional (non-warranted) information
at 25 °C, which may be useful in the application of the product.
Unless otherwise noted, this data sheet applies to units with serial numbers
ending with 50420000 or greater.
www.keysight.com/find/e8257d
M9703A 12-Bit High-Speed Digitizer
http://literature.cdn.keysight.com/litweb/pdf/M9703-90001.pdf
