AXIe Chassis and Modules
M9505A 5-Slot AXIe Chassis at a Glance
M9505A 5-Slot AXIe Chassis at a Glance
The M9505A is shipped with bumpers and two carry handles installed for benchtop
use (these remove for rack mounting), Slot 1 open and filler panel modules installed in
Slots 2 through 5. The front panel is shown below:
Chassis and Module Details
Detailed instructions for installation, configuration, operation, troubleshooting and
service can be found in the M9502A/M9505A AXIe Chassis User Guide, provided in
PDF format.
http://literature.cdn.keysight.com/litweb/pdf/M9502-90001.pdf
Topics included in this manual are:
- Introduction
M9502A 2-Slot AXIe Chassis at a Glance
M9505A 5-Slot AXIe Chassis at a Glance
AXIe Embedded System Module (ESM)
AXIe Embedded System Module (ESM) Option U20 with USB
AXIe Instrument Modules
AXIe System Block Diagram
Performing the Startup Steps
Step 1: Unpack and Inspect the Chassis
Inspect for damage
If You Should Need to Return the Chassis for Service
22 Keysight Y1299A-003 MAC Reference Solution Startup Guide
