Contents
Contents vii
Multi-Channel Antenna Calibration (MAC) Introduction 9
Typical System Performance 9
The MAC Reference Solution 10
System Software 10
System Hardware 11
Product specifications & characteristics 13
M9703A AXIe 12-bit digitizer/wide-band receiver 13
M9362A-D01 PXIe microwave quad downconverter 13
M9352A PXI hybrid amplifier/attenuator 14
N5183B MXG microwave analog signal generator 14
N5193A UXG microwave agile signal generator 14
E8257D PSG analog signal generator 15
M9703A 12-Bit High-Speed Digitizer 15
Unpack and Inspect 16
ESD 16
Inspect for Damage 17
Return an Instrument for Service 17
PXIe Chassis and Modules 19
PXIe Chassis 19
PXIe Modules 20
AXIe Chassis and Modules 21
Introduction 21
M9502A 2-Slot AXIe Chassis at a Glance 21
M9505A 5-Slot AXIe Chassis at a Glance 22
Chassis and Module Details 22
MAC Demo Software 24
Setup tab 25
Preferences pane 29
Choosing the Default Export Folder 31
Analysis tab 33
Status tab 35
