MAC Demo Software
Chassis and Module Details
MAC Demo Software
The MACDemo Software has been designed to assist in the development of the
overall test system software.
The MACDemo Software is installed on the CD that accompanies the system (Y1299-
10003). A program such as WinZip will need to be installed on you PC to unzip the
MACDemo Software.
To load and setup the MACDemo Software from the CD, use the following procedure:
1. Insert and launch the Y1299-10003 CD on your PC
2. Once launched, select the Extract MAC Demo Software button on the Y1299-
10003 CD browser
3. Unzip the self extracting zip file to a folder on your PC
4. Once extracted, navigate to the MultiAntennaArrayCalibration.exe file to run
the demonstration software
In Win 8 the user should run the self-extracting zip file as administrator by manually
opening CD. The user can then change the path of the directory for the self-extracting
zip file.
In order to run the MultiAntennaArrayCalibration.exe correctly, the following software
needs to be installed on your PC:
NETframework4.5 (Visual Studio 2012) in Windows 7 or 8 (64 bit). You will be
prompted to load this when selecting the MultiAntennaArrayCalibration.exe file
The latest AgMD1 IVIdriver software, which can be obtained from here:
http://www.keysight.com/main/software.jspx?ckey=2000051&lc=eng&c
c=US&nid=-11143.0.00&id=2000051
Install the version 1.13.7 (this is the package version, whereas the DLL
version inside is 1.6.4).
If you want to try out the code in simulate mode, you also need to copy
the included MACsim.dat file into your C:\tmp directory (create C:\tmp if
you don’t already have this folder).
24 Keysight Y1299A-003 MAC Reference Solution Startup Guide
