12 X-Series Signal Analyzers Getting Started and Troubleshooting Guide
Quick Start
Turning on the Analyzer the First Time
Turning on the Analyzer the First Time
Initial power-on of the analyzer can be accomplished using the following
methods:
Initializing the analyzer
Steps Actions Notes
1. Power on the analyzer a. Position the analyzer so
you have easy access to
the power cord and plug
it in.
b. Press the power switch
(located in the lower left
corner of the analyzer’s
front panel) to turn the
analyzer on.
See
“Instrument Location and Rack
Mounting Requirements
and “Power
requirements” on page 18
for more details.
The analyzer can require more than 5 minutes to
power-on.
The Keysight Technologies screen appears followed by a
screen that allows you to select Windows10 or the
Recovery option.
2. Viewing the End-User
License Agreement
After a brief startup, the following window appears giving you information about the
End-User License Agreement.
At this time, it is safe to turn off the instrument before initializing the software.
3. Reboot and log on
— Click
OK
When the instrument restarts, the following message
window appears:
To Next Page
