26 X-Series Signal Analyzers Getting Started and Troubleshooting Guide
Front and Rear Panel Features
Front-Panel Features
12 Probe Power Supplies power for external high frequency probes and accessories.
13 Ext Mixer Provides LO output signal to and receives IF input signals from an external mixer. See
the Specifications Guide for details on signal levels.
Not available on CXA or RF/microwave EXA (Option 503, 507, 513, or 526).
14 Power Standby/ On Turns the analyzer on. A green light indicates power on. A yellow light indicates
standby mode.
The front-panel switch is a standby switch, not a LINE switch
(disconnecting device). The analyzer continues to draw
power even when the front-panel switch is in standby.
The main power cord can be used as the system
disconnecting device. It disconnects the mains circuits from
the mains supply.
Item
Description
# Name
To Next Page
