Security Features and Document of Volatility
Disk Drive Removal Procedure
39
6 Disk Drive Removal Procedure
This chapter describes the procedures for physical removal of the instrument’s
disk drive.
TIP Application License keys are stored in EEPROM on the A7 Midplane Assembly
(as described in Item 18 of Table 4-1 on page 12). Therefore, when replacing
the Disk Drive, you do no
t need to back up and restore the license keys.
When installing a replacement Disk Drive, ensure that the instrument
software revision on the replacement drive matches that of the original drive.
To remove the disk drive, follow the steps below. The numbered items in the
figures correspond to the step numbers in the procedure.
CAUTION Before removing the disk drive, ensure that the instrument’s power is turned
off.
