Characteristics and Environmental Conditions
The following table contains a partial list of specifications and characteristics for
the Infiniium S-Series oscilloscopes. For a full list of specifications and
characteristics, see the data sheets at www.keysight.com/find/S-series.
Warranted specifications are tested in Chapter 3. Specifications are valid after a
30-minute warm-up period, and within
± 5° C from the temperature at which the
last user calibration was performed.
Environment Indoor use only
Ambient temperature Operating: 5 °C to +40 °C
Non-operating: –40 °C to +65 °C
Humidity Operating: up to 80% relative humidity (non-condensing) at +40 °C
Non-operating: up to 90% relative humidity at +65 °C
Altitude Operating: up to 3,000 meters (9,842 feet)
Non-operating: up to 15,300 meters (50,000 feet)
Weight 11.8 kg (26 lbs)
Dimensions 16.8 in (43 cm) wide, 12.9 in (33 cm) tall, and 9 in (23 cm) deep
Safety UL61010-1 3
rd
edition
CAN/CSA-22.2 No. 61010-1-12 3
rd
edition
Installation Category II
Power Requirements 100-120 V, 50/60/400 Hz
100-240 V, 50/60 Hz
380 W Max
Voltage Fluctuations Note that the main supply voltage fluctuations are not to exceed ±10% of
the nominal supply voltage.
Pollution Degree The Infiniium S-Series oscilloscopes may be operated in environments of
Pollution Degree 2.
Pollution Degree
Definitions
Pollution Degree 1: No pollution or only dry, non-conductive pollution
occurs. The pollution has no influence. Example: A clean room or
climate-controlled office environment.
Pollution Degree 2. Normally only dry non-conductive pollution occurs.
Occasionally a temporary conductivity caused by condensation may occur.
Example: General indoor environment.
Pollution Degree 3: Conductive pollution occurs, or dry, non-conductive
pollution occurs which becomes conductive due to condensation which is
expected. Example: Sheltered outdoor environment.
