Note: Refer to Keysight Technologies Millimeter-Wave Network Analyzers 10 MHz to 110 GHz, with Extensions to 1.1 THz Technical
Overview part number 5989-7620EN for the most current information.
Conguring a 10 MHz to 110 GHz solution using separate components
Conguration of the single sweep solution using individual system components is easily done by selecting one each of the following
components
1. 67 GHz PNA with congurable test set or PNA-X network analyzer
2. Either a N5261A (2-port) or N5262A (4-port) millimeter-wave test set controller
3. A set of N5250CX10 67 GHz to 110 GHz frequency extenders
The following table provides a list of available system components that may be selected to create a 10 MHz to 110 GHz solution.
Product/ options Description
67 GHz PNA-X/PNA network analyzer1
N5227A -201/ 219 or
N5247A -200
2-ports, single source 10 MHz to 67 GHz PNA-X or PNA with congurable test set
N5227A-401/ 419 or
N5247A-400
4-ports, dual source PNA-X or PNA with congurable test set
N5227A -020
N5247A -020 Required
Adds rear panel direct access IF Inputs for either N5227A or N5247A
2
2-port millimeter wave test set controller3
N5261A 2-port millimeter-wave test set controller for PNA/ PNA-X based conguration
N5261A-112, required A set of cables for 1.85 mm connection to a 2-port PNA/ PNA-X N5247A
Must choose one of the following connection cables. One per module.
N5261A-501 A single set (1-port) of RF,LO,DC and IF cables for connection to a single T/R millimeter module, 48"
N5261A-502 A single set (1-port) of RF,LO,DC and IF cables for connection to a single T/R millimeter module, 2 meter
N5261A-503 A single set (1-port) of RF,LO,DC and IF cables for connection to a single T/R millimeter module, 3 meter
N5261A-505 A single set (1-port) of RF,LO,DC and IF cables for connection to a single T/R millimeter module, 5 meter
4
4-port millimeter wave test set controller3
N5262A 4-port millimeter-wave test set controller for PNA/ PNA-X based conguration
N5262A-114, required A set of cables for 1.85 mm connection to a 4-port PNA/ PNA-X N5247A
Must choose one of the following connection cables. One per module.
N5262A-501 A single set of RF,LO,DC and IF cables for connection to a single T/R millimeter module, 48"
N5262A-502 A single set of RF,LO,DC and IF cables for connection to a single T/R millimeter module, 2 meter
N5262A-503 A single set of RF,LO,DC and IF cables for connection to a single T/R millimeter module, 3 meter
N5262A-505 A single set of RF,LO,DC and IF cables for connection to a single T/R millimeter module, 5 meter
4
Millimeter-wave frequency extenders
N5250CX10-L05 67 to 110 GHz, left T/R module & 1.00 mm combiner assembly without adjustable attenuator, or bias tee
N5250CX10-L10 67 to 110 GHz, left T/R module & 1.00 mm combiner assembly with adjustable attenuator, and no bias tee
N5250CX10-L15 67 to 110 GHz, left T/R module & 1.00 mm combiner assembly with bias tee, and no adjustable attenuator
N5250CX10-L20 67 to 110 GHz, left T/R module & 1.00 mm combiner assembly with adjustable attenuator and bias tee
N5250CX10-R10 67 to 110 GHz, right T/R module & 1.00 mm combiner assembly without adjustable attenuator, or bias tee
N5250CX10-R15 67 to 110 GHz, right T/R module & 1.00 mm combiner assembly with adjustable attenuator, and no bias tee
N5250CX10-R20 67 to 110 GHz, right T/R module & 1.00 mm combiner assembly with bias tee and no adjustable attenuator
N5250CX10-R30 67 to 110 GHz, right T/R module & 1.00 mm combiner assembly with adjustable attenuator and bias tee
N5227A PNA or N5247A PNA-X based single sweep solution hardware conguration table
Notes
1. For PNA/PNA-X options select either a 2-port option for a 2-port 110 GHz conguration or a 4-port option for 4-port 110 GHz solutions.
2. Option 020 is a required option that allows for direct connection of the IF into the back of the PNA/PNA-X.
3. The millimeter-wave test set controller will include cables and the lock link kit to interface to the PNA/PNA-X when either Option 112 or 114 is selected.
4. When selecting Option 505, cable set external RF and LO ampliers will be required because of cable loss around 6.6 dB.
5. The Kelvin bias-tees have a voltage rating of 40 volts and a maximum of 0.5 amps.
Broadband Solution Conguration
