Conguration of a banded solution is similar to conguration of a single sweep solution
using separate components. With the support of several frequency extenders and vec-
tor network analyzer options, the banded solutions offer industry leading exibility and
extensibility for measurements to 1.1 THz.
To congure basic hardware required for a particular solution select the
following three components:
1. Performance network analyzer congured to support either a test set controller or
direct connection of the frequency extenders
2. 2- or 4-port millimeter test set controller, not required for direct connection. See page
13 for Supported measurement capability.
3. Select the required frequency extenders for the frequency coverage required
Banded Solution Conguration
Product
model
Description Minimum option
required for test
set controller con-
nection
Minimum option required
for direct connection PNA
Minimum option required for direct
connection PNA-X
N5222A or
N5242A
2-port 26.5 GHz PNA or
PNA-X network analyzer
Option 020 Unsupported Option 200 or 200/219 and Option 080
with Option 224
N5222A or
N5242A
4-port 26.5 GHz PNA or
PNA-X network analyzer
Option 020 Requires Option 080 and Options
401, or 417, or 419 for N5222A
Option 400 or 400/419 and Option 080
N5224A or
N5244A
2-port 43.5 GHz PNA or
PNA-X network analyzer
Option 020 Unsupported Option 200 or 200/219 and Option 080
with Option 224
N5224A or
N5244A
4-port 43.5 GHz PNA or
PNA-X network analyzer
Option 020 Requires Option 080 and Options
401, or 417, or 419 for N5224A
Option 400 or 400/419 and Option 080
N5225A or
N5245A
2-port 50 GHz PNA or
PNA-X network analyzer
Option 020 Unsupported Option 200 or 200/219 and Option 080
with Option 224
N5225A or
N5245A
4-port 50 GHz PNA or
PNA-X network analyzer
Option 020 Requires Option 080 and Options
401, or 417, or 419 for N5225A
Option 400 or 400/419 and Option 080
N5227A or
N5247A
2-port 67 GHz PNA or
PNA-X network analyzer
Option 020 Unsupported Option 200 or 200/219 and Option 080
with Option 224
N5227A or
N5247A
4-port 67 GHz PNA or
PNA-X network analyzer
Option 020 Requires Option 080 and Options
401, or 417, or 419 for N5227A
Option 400 or 400/419 and Option 080
Supported PNA and PNA-X congurations for banded waveguide
