Page #47 background image
LAN
To transmit
8511A
Coupler
83631B
Synthesized source
8530A
Microwave receiver
Personal computer
Positioner/controller
RCS automation
software
HP-IB
antenna
RF source
To computer
Figure 29. 85301 RCS system migration to PNA-X N5242A network analyzer.
Migration examples (continued)
47 | Keysight | Antenna Test – Selection Guide
