Keysight U1610A Quick Start Guide

8 Keysight U1610/20A Quick Start Guide
Product Outlook
Scope terminals
Display screen
Function softkeys
To perform the
function displayed
above each softkey.
Acquisition and
function controls
To access the scope,
meter, logger,
system, and help
functions.
Vertical controls
To set the
vertical scaling
(volt/div) and
vertical offset.
Power key
USB interface
connector and
DC power
inlet
Directional keys
Horizontal controls
To control the sweep speed
(sec/div) and horizontal position
of the waveform. Use
to zoom into the waveform.
Meter terminals

Keysight U1610A Specifications

General

Brand	Keysight
Model	U1610A
Category	Test Equipment
Language	English
