Installation
8 SE45w
With some applications the motor leads may need to be rotated to avoid interference with other
components. If rotation is required please give us a call at 1-877-346-2050 for instructions or visit
our website at www.kfiproducts.com and look in the Instructions section.
Winch Wiring Diagram
