KFI SE45w - Winch Parts List

SE45w Specifications
SE45w 15
Winch Parts List
No.
Part #
Description
Qty
1
450100-C
Motor Assembly
1
2
450001
Coupling, 1
1
3
450002
Spring, Coupling
1
4
450003
Coupling, 2
1
5
450200A-BF
Drum Assembly
Black Flat
1
6
450004-BF
Gear Housing / End
Bearing Black Flat
1
7
450005-A
Gear Ring
1
8
450006
Gear Carrier Assembly,
Output
1
9
450007
Gear Carrier Assembly,
Intermediate
1
10
450008
Gear Carrier Assembly,
Input
1
11
450009
Gear-Input, Sun
1
12
450010
Gear, Fixed
1
13
250021
Clutch Bushing
1
14
250002-B
Washer Φ6, Flat
Black Zinc
6
15
450011-B
Bolt M6x25 Black Zinc
4
16
450012-B
Bolt M6x100 Black Zinc
2
17
450013
Seal
2
18
450014
Friction Washer
2
19
450015
Retaining Ring
1
20
450016
O-Ring Seal
1
21
450017
Drum Bushing
2
22
400018
Hexagonal Shaft
1
23
400008-B
Tie Bar Φ10 Black Zinc
2
24
451000
Synthetic Cable 15/64”
x 50ft
1
25
SE-HOOK
¼” Clevis Hook Black Zinc
1
26
250030-B
Strap-Black
1
27
250032-B
Bolt M8x25 Black Zinc
4
28
250063-B
Washer Φ8, Locking
Black Zinc
4
29
250070-B
Washer Φ8, Flat
Black Zinc
4
30
100695
Wide Fairlead Bracket
Black Flat
1
31
250033-B
Bolt M10x20 Black Zinc
2
32
250036-B
Locking Nut M10
Black Zinc
2
33
SE-WRF
Roller Fairlead
Black Flat & POM Rollers
1
34
400015-B
Winch Wires
2
35
450016-B
Battery Wires
2
36
400010-BF
Tie Bar Φ8 Black Flat
1
37
450026-B
Bolt M4x25 Black Zinc
2
38
450027-B
Washer Φ4, Flat Black Zinc
2
39
ATV-MR
Handle Bar Remote
1
40
250062
Wire Tap
2
No.
Part #
Description
Qty
41
250061
Terminal Protector
8
42
250045-BF
Handlebar Switch Clamp
Black Flat
2
43
250046-BF
Handlebar Switch
Extender Black Flat
1
44
250047-BF
Handlebar Switch
Mounting Angle Black Flat
1
45
250048-B
Bolt M5x25 Black Zinc
4
46
250049-B
Washer Φ5, Flat Black Zinc
5
47
250050-B
Washer Φ5, Locking
Black Zinc
3
48
250051-B
Bolt M5x18 Black Zinc
1
49
250052-B
Nut M5 Black Zinc
3
50
250053-B
Screw #6-32x9/32”
Black Zinc
4
51
250054-B
Washer Φ6, Locking
Black Zinc
2
52
ATV-CONT
Contactor
1
53
ATV-SCHS
Split Cable Hook Stopper
1
54
250065-B
Screw M6x25 Black Zinc
4
55
250066-B
Washer Φ6, Flat Black Zinc
4
56
250067-B
Washer Φ6, Locking
Black Zinc
4
57
250068-B
Locking Nut M6
Black Zinc
6
58
250069-B
Screw m6x1.0x20
Black Zinc
2
59
250071-B
Nut M5 Black Zinc
2
60
250059-B
Hand Remote Assembly
Black
1
61
250064
Hand Remote 3-Pin
Connector
1
62
450028-B
Bolt M8x30 Black Zinc
4
63
250035-B
Washer Φ10, Locking
Black Zinc
2
64
400032-BF
UTV Switch Bracket Black
1
65
400033-B
Bolt M6x16 Black Zinc
2
66
400034-B
Threading Screw M4x12
Black Zinc
2
67
450030-B
Washer Φ4, Flat Black Zinc
2
68
450031
Cross Recess Pan Head
Screw M6 x 8
1
69
450029
Spring
1
70
GB2760BB06
002-SS
Radial Ball Bearing 6002
Sealed
1
71
250019
Axis Support Bushing
1
72
450032
Cam Clutch Gear
1
73
250012
Spring
1
74
450033-BF
Clutch Cover Black Flat
1
75
GB2760BB16
002-SS
Radial Ball Bearing 16002
Sealed
1
76
250016-BF
Clutch Cap Black Flat
1
77
250011
Retaining Ring Clip
1
78
250017
Locking Washer Φ6
1
79
250018
Cap Screw M6 x 16
1
