SE45w Specifications
SE45w 13
SE45w Specifications
Performance Specifications
Rated Pull 4,500 lbs (2041 kg)
Gear Reduction Ratio 166:1
Motor Permanent Magnet
1.7 HP (DC 12V)
Drum Size 2.0” (D) x 4.9” (L)
50.8 mm (D) x 125.0 mm (L)
Synthetic Cable 15/64” (D) x 50.0’ (L)
6 mm (D) x 15.2 m (L)
(47 useable feet with five
wraps on the winch drum)
Weight 35.3 lbs. (complete kit)
Height 4.82 inches (122.5 mm)
Width 4.55 inches (115.5 mm)
Length 16.3 inches (415 mm)
Bolt Pattern 6.60” x 3” (168mm x 76 mm)
Line speed and Motor Current (First layer)
Line pull Max
lbs
0
1000
2000
3000
4500
kgs
0
454
907
1361
2041
Line speed
(12VDC)
FPM
12.8
9.8
8.5
6.9
4.6
MPM
3.9
3.0
2.6
2.1
1.4
Max Current
amps
28
80
130
180
280
Cooling Time
minutes
5
5
5
5
5
Line pull and cable capacity
Layers of cable on drum
1
2
3
4
Max pulling capacity per
layer
lbs
4500
3715
3163
2754
kgs
2041
1687
1436
1250
Cable capacity
per layer
ft
12.2
26.2
41.9
50
m
3.7
8.0
12.8
15.2
