Assemble units as described herein only. To do otherwise
may result in instability. All screws, nuts and bolts must be
tightened securely and must be checked periodically after
assembly. Failure to assemble properly, or to secure parts
may result in assembly failure and personal injury.
Seminar
TM
Tables with 4-Wire Power System - Floor Anchor Specications
Assembly Instructions
wood
concrete
Bolt Detail
punch clearance hole
in carpet before drilling
#12.7510.KIT4
/”x 2 /
” hex washer
head tapping screw
31
82
#12.7503.KIT4
/”Hilti KH-EZ x 2 /”
Max. Torque: 18 ft/lbs
15
48
punch clearance hole
in carpet before drilling
13
/”x 2 /”
minimum hole depth
44
1 /”
min.
1
2
3”
min.
minimum 3000 PSI
concrete compressive
strength with normal
weight aggregate
1 /”minimum free
of obstructions
1
2
pre-drill /”hole prior
to tapping screw installation
9
32
minimum of two layers of /”
APA graded plywood
3
4
Grade 3 bolt
/”-16 x 2 /”min.
31
82
/”
Grade 3 washer
3
8
/”Grade 3
lock washer
3
8
/”-16
Grade 3 nut
3
8
/”Grade 3
washer
3
8
raised access floor
pre-drill /”hole
prior to bolt assembly
installation
7
16
raised access floor to
have a minimum weight
rating of 125 PSF.
Note: KI is not responisble
for how flooring is secured.
See applied loads.
Note: If any other flooring types exist that are
not shown, please provide you KI contact
with the detailed floor specifications.
#12.7530.KIT4
Grade 3 nut, bolt, and washer
/”-16 x 2 /”minimum
31
82
Applied Load Per Anchor With A Three Time Safety Factor
Tension (lbs)
1080
Shear (lbs)
240
Actual Calculated Moment At Base (in-lbs) With 325lb Load
4650
Floor Anchor Specifications
(4) /”
diameter holes
1
2
3 /”
3
4
5
/”
16
1
3
/”
4
2”
4”
8”
