Kia Optima 2004 - Page 176

Engine compartment
6-11
2MS106001A
COND FAN
20A
PWR WIND
40A
IGN SW-1
30A
ABS 2
20A
FUSE
PULLER
ABS 1
40A
1
COND FAN
HI-1
RAD FAN
HI-1
COND FAN
HI-2
COND
FAN LO
HORN
FR FOG
HEAD LP
HI
WIPER MTR
STARTER
RAD FAN
HI-2
RAD FAN LO
IGN SW-2
30A
HEAD LP LO
RAD
FAN MTR
30A
A/CON
6
2 7
3 8
11
13
14
15 17
18
24
23
27
28
20 26
16 21
22 29
19 25
12
9
10
4
5
1 FUEL PUMP (20A)
2 HD LP LO (15A)
3 ABS (10A)
4 INJECTOR (10A)
5 A/C COMPR (10A)
6 ATM RLY (20A)
7 ECU RLY (30A)
8 IG COIL (20A)
9
10
O2SNSR (15A)
ECU (15A)
11 HORN (10A)
12 HEAD LP HI (15A)
13 HEAD LP WASH (20A)
14 DRL (15A)
15 FR FOG (15A)
16 DIODE-1
21
DIODE-2
22
BLOWER (30A)
23
PWR FUSE-2 (30A)
24
PWR AMP (20A)
27 PWR FUSE-1 (30A)
28 ECU (10A)
29 RR HTD (30A)
NOT USED
25
SUNROOF (15A)
26
TAIL LP (20A)
17 SPARE (30A)
18 SPARE (20A)
19 SPARE (15A)
20
SPARE (10A)
USE THE DESIGNATED FUSE AND RELAY ONLY
