IN CASE OF EMERGENCY
6-12
DESCRIPTION FUSE RATING PROTECTED COMPARTMENTS
COND FAN 20A Condenser fan
PWR WIND 40A Power window
ABS 2 20A ABS
IGN SW-1 30A Ignition switch
ABS 1 40A ABS
IGN SW-2 30A Ignition switch
RAD FAN MTR 30A Radiator fan motor
FUEL PUMP 20A Fuel pump
HD LP LO 15A Headlights (LO)
ABS 10A ABS
INJECTOR 10A Injector
A/C COMPR 10A Air-con compressor
ATM RLY 20A ATM Relay
ECU RLY 30A Engine control unit relay
IG COIL 20A Ignition coil
O2 SNSR 15A Oxygen sensor
ECU 15A Engine control unit
DESCRIPTION FUSE RATING PROTECTED COMPARTMENTS
HORN 10A Horn
HEAD LP HI 15A Headlights (HI)
HEAD LP WASH 20A -
DRL 15A DRL
FR FOG 15A Front fog lights
DIODE-1 - Diode 1
SPARE 30A Spare fuse
SPARE 20A Spare fuse
SPARE 15A Spare fuse
SPARE 10A Spare fuse
DIODE-2 - Diode 2
BLOWER 30A Blower
PWR FUSE-2 30A Power fuse 2
PWR AMP 20A Power amp
SUNROOF 15A Sunroof
TAIL LP 20A Tail lights
PWR FUSE-1 30A Power fuse 1
ECU 10A ECU
RR HTD 30A Rear window defroster
