775
Maintenance
Fuse Name Symbol Fuse rating Protected Component
VACUUM PUMP 20A -
A/BAG 15A
SRS Control Module, Telltale Lamp (Europe),
Seat Belt Reminder Indicator (Australia)
P/WDW LH 25A
Driver Safety Power Window Module (LHD), Passenger Safety Power Window Module (RHD),
Rear Safety Power, Window Module LH, Power Window LH Relay
AMP 30A AMP
BRAKE SWITCH 7.5A
Smart Key Control Module, Start Stop Button Switch,
FOB Holder, Stop Lamp Switch
SPARE 10A -
MDPS 10A
Crash Pad Switch, EPS Control Module (With MDPS),
Steering Angle Sensor (W/O MDPS), ATM Lever Indicator,
EPB Switch, EPB Control Module
PDM3 7.5A Smart Key Control Module (With Smart Key)
P/WDW RH 25A
Driver Safety Power Window Module (RHD),
Passenger Safety Power Window Module (LHD),
Rear Safety Power Window Module RH,
Power Window RH Relay
P/SEAT
DRV
30A
Driver IMS Module, Driver Seat Manual Switch,
Driver Lumbar Support Switch (2WAY)
DR LOCK 20A
Door Lock/Unlock Relay, Dead Lock Relay (RHD),
Turn Signal Lamp Sound Relay
