Fuse Name Symbol Fuse rating Protected Component
SUNROOF 20A Panorama Sunroof
IG1 20A E/R Fuse & Relay Box (Fuse - F10, F11, F12, F13)
AUDIO
15A Audio, ISG Low DC-DC Converter (Audio)
ROOM LP
10A
Driver/Passenger Smart Key Outside Handle (With Smart Key),
Driver/Passenger Door Lamp, A/C Control Module,
Ignition Key ILL. & Door Warning Switch (W/O Smart Key),
RF Receiver (With Smart Key), Driver IMS Module, BCM, Data Link Connector,
Driver/Passenger Door Scuff Lamp, Power Outside Mirror Switch,
Auto Light & Photo Sensor (W/O B/Alarm), Lamp Auto Cut Relay, Instrument Cluster
