Fuses
Engine Room Junction Block
Fuse Name Symbol Fuse rating Circuit Protected
MDPS1 80 A MDPS (Motor Driven Power Steering) Unit
BATT5 60 A
PCB Block (Fuse Name: BATTERY C/FAN, WIPER, HORN,
ECU2, Engine Control Relay)
BATT2 60 A
ICU Junction Block (SPOC+(4CH), SPOC+(4CH), IPS(1CH),
IPS(1CH), IPS(1CH))
BATT3 60 A
ICU Junction Block (SPOC+(4CH), SPOC+(4CH), IPS(2CH),
IPS(2CH), IPS(2CH), IPS(1CH))
BATT4 50 A
ICU Junction Block (Fuse Name: TAIL GATE, P/WDW RH,
P/WDW RH, P/SEAT DRV, S/HEATER FRT, IG3, P/SEAT
PASS, MDPS (Motor Driven Power Steering), SUNROOF
2, SUNROOF 1)
COOLING FAN1 60 A COOLING FAN 1 Relay
IEB1 60 A Integrated Electric Brake Module
BLOWER 40 A BLOWER Relay
IG1 40 A PDM 2 (IG1) Relay, PDM 1 (ACC) Relay
IG2 40 A PDM 3 (IG2) Relay
COOLING FAN2 80 A Cooling Fan Controller
IEB3 60 A Integrated Electric Brake Module
PTC HEATER1 50 A PTC HEATER 1 Relay
PTC HEATER2 50 A PTC HEATER 2 Relay
CLUTCH ACTUA -
TOR
40 A Clutch Actuator (HEV)
POWER OUTLET3 20 A Rear Power Outlet
POWER OUTLET2 20 A Power Outlet RH
IG3 2 10 A
Instrument Cluster, Charger Lamp, Audio, Audio/Video
& Navigation Head Unit
DCT3 15 A TCM (Transmission Control Module)
EWP 10 A Electric Water Pump (Engine)
FUEL PUMP 20 A FUEL PUMP Relay
1
5
2
3
4
1
IEB
1
IG1
IG2
2
IEB
3
PTC
HEATER
1
PTC
HEATER
2
CLUTCH
ACTUATOR
POWER
OUTLET
3
POWER
OUTLET
2
IG3
2
DCT
3
EWP
FUEL
PUMP
