Fuses
PCB Block
Fuse Name Symbol Fuse rating Circuit Protected
IG3 1 10 A Engine Room Sub Block (PTC HEATER 2 Relay)
HEV HCU2 15 A
HPCU (Hybrid Power Control Unit), Clutch Actuator
(HEV)
IEB4 10 A
Integrated Electric Brake Module, Multipurpose Check
Connector
DCT4 15 A Sport Mode Switch
SENSOR3 10 A Engine Room Junction Block (FUEL PUMP Relay)
BATTERY C/FAN 15 A Engine Room Junction Block (BATTERY C/FAN Relay)
WIPER 25 A Front Wiper Relay
HORN 15 A Horn Relay
SENSOR2 10 A
Engine Room Junction Block (COOLING FAN 1 Relay, TIV
Relay), Camshaft Position Sensor #1 (Intake), Cam
-
shaft Position Sensor #2 (Exhaust), Purge Control
Solenoid Valve, Ma Air Flow Sensor, Oil Control Valve #1
(Intake), Oil Control Valve #2 (Exhaust)
ECU1 20 A ECM (Engine Control Module)
SENSOR1 15 A Oxygen Sensor (Up/Down)
IGN COIL 20 A Ignition Coil #1/#2/#3/#4
ECU2 15 A ECM (Engine Control Module)
IG3
4
IEB
4
DC
BATTERY
C/FAN
S2
E1
S1
IGN
COIL
E2
