CX.1-SERIES AMPLIFIERS
OWNER’S MANUAL
INSTALLATION
Mounting: Choose a structurally sound location to mount your KICKER amplifi er. Make sure there are no items
behind the area where the screws will be driven. Choose a location that allows at least 4” (10cm) of open
ventilation for the amplifi er. If possible, mount the amplifi er in the climate-controlled passenger compartment. Drill
four holes using a 7/64” (3mm) bit and use the supplied #8 screws to mount the amplifi er.
The KICKER CX Amplifi ers are capable of space-saving vertical mounting. Use a 2.5mm hex key (Allen wrench)
to loosen the endpanel, remove the existing brackets, then insert and tighten the double-slotted brackets to the
amplifi er as illustrated on the next page.
PERFORMANCE
Authorized KICKER Dealer:
Purchase Date:
Model Number:
Serial Number:
Model: CX300.1 CX600.1 CX1200.1
RMS Power
@ 14.4V, 4 mono, d 1% THD+N
@ 14.4V, 2 mono, d 1% THD+N
150W x 1
300W x 1
300W x 1
600W x 1
600W x 1
1200W x 1
Length | in [mm] 8-1/8 [210] 8-1/8 [210] 12-1/16 [310]
Specifi cations common to all models:
Height | in [mm] 2-3/8 [60]
Width | in [mm] 7-3/16 [180]
Frequency Response ± 1dB 25Hz–200Hz
Signal-to-noise Ratio >95dB, A-weighted, re: rated power
Input Sensitivity Low Level: 125mV–5V
High Level: 250mV–10V
Electronic Crossover Variable Lo-pass 50Hz–200Hz, 12dB/octave
Bass Boost Variable 0–12dB @ 40Hz
Subsonic Filter 25Hz, 24dB/octave
Remote Bass Yes [sold separately]
Pro Tip: To get the best performance from your new KICKER Amplifi er and extend the warranty by 1 year, use
genuine KICKER accessories and wiring.
MODEL: CX300.1 / CX600.1 / CX1200.1
