Kicker CX1200.1 User Manual

4
GND REM +12V
12V
battery
external fuse
remote turn-on
(see page 5)
bare-metal
chassis ground
bare-metal
chassis ground
d18”
(45cm)
d24”
(60cm)
woofer
MONO OPERATION
minimum impedance of 2 ohms
Model External Fuse
(sold separately)
Power/Ground Wire KICKER Wiring Kit
CX300.1 1 x 40 Ampere 8 Gauge PK8, ZCK84
CX600.1 1 x 80 Ampere 4 Gauge PK4, CK44, ZCK44
CX1200.1 1 x 150 Ampere 4 Gauge PK4, CK44, ZCK44
Install a fuse within 18” (45cm) of the battery and in-line with the power cable connected to your amplifi er. If you
ever need to remove the amplifi er from the vehicle after it has been installed, the ground wire should be the last
wire disconnected from the amplifi er--just the opposite as when you installed it.
2012 CX Mono Amps Rev I.indd 4 6/22/2012 2:32:29 PM

Kicker CX1200.1 Specifications

General

Bass boost	0 - 12 dB
Amplifier class	-
Input sensitivity	250 mV
Low pass filter range	50 - 200 Hz
High pass filter range	25 - 200 Hz
Signal-to-Noise Ratio (SNR)	95 dB
Number of amplifier channels	1 channels
RMS power output per channel (2 Ohm)	1200 W
RMS power output per channel (4 Ohm)	600 W
Product color	Black

Weight and Dimensions

Depth	163.1 mm
Width	161.8 mm
Height	86 mm
