lfKICKER
MODEL:
Authorized
KICKER
Dealer:
Purchase
Date:
Model Number:
Serial Number:
PERFORMANCE
Model:
RMS Power
@ 14.4V,
40
mono,
s
1%
THD+N
@ 14.4V,
20
mono,
s
1%
THD+N
Length,
in.
(em)
Electronic Crossover
Subsonic
Filter
Bass Boost
Specifications common
to
all models:
Height,
in.
(mm)
Width,
in
.
(mm)
Frequency Response
±
1
dB
Signal-to-noise
Ratio
Input
Sensitivity
Remote Bass
DX.1-SERIES
AMPLIFIERS
OWNER'S
MANUAL
DX250.1/
DX500.1/
DX1000.1
DX250.1
140W
X
1
250W
x 1
10-1
/4"
(26)
Fixed,
80Hz
24dB/octave
Fixed, 25Hz
24dB/octave
Selectable,
0/9dB
@40Hz
2-1/4"
(57)
8-5/16JI
(211)
20Hz-200Hz
DX500.1
275W
X
1
500W
X
1
10-1
/4" (26)
DX1000.1
550Wx
1
1000Wx
1
10-1
/4"
(26)
Variable
lo-pass 50Hz-200Hz
1 8d
B/
octave
Variable hi-pass
•1 0Hz-30Hz
18dB/octave
Variable
0-
12dB
@
40Hz
>95dB, A-weighted,
re:
rated power
Low Level: ·125mV-5V
High Level:
250mV-1
OV
Yes
(not included)
Yes
Yes
Pro Tip:
To
get the best performance from your new
KICKER
Amplifier and extend the warranty by 1
year,
use
genuine
KICKER
accessories and wiring.
INSTALLATION
Mounting:
Choose a structurally sound location to mount your
KICKER
amplifier. Make sure there are no items
behind the area where the screws
will
be driven. Choose a location that allows
at
least
4"
(1
Ocm)
of open
ventilation for the amplifier.
If
possible, mount the amplifier
in
the climate-controlled passenger compartment.
Drill
four holes using a 7 /64" (3mm) bit and use the supplied #8 screws to mount the amplifier.
Wiring:
Disconnect the vehicle's battery to avoid
an
electrical short. Then, connect the ground wire to the
amplifier. Make the ground wire short,
24"
(60cm) or less, and connect
it
to a paint-and-corrosion-free, solid,
metal area of the vehicle's chassis. Adding
an
additional ground wire of this same gauge (or larger) between the
battery's negative post and the vehicle chassis
is
recommended.
