Chapter 3: Programming
GSA-REL Technical Reference Manual 41
Caution: Do not include the releasing circuits (RELEASE 1 & 2) in this response.
5. Click the Responses tab, click the Response Type arrow, and then select
Active.
6. Click Outputs, select the device labeled GSA-REL1 A005 PRERELEASE 1 &
2, and then click OK.
Make sure you select the PRERELEASE device, not the RELEASE device.
Step 6: Create an AND group release response
Here, you create a release response that activates the release circuits when two
or more detectors in the protected area signal an alarm.
Note: To comply with NFPA 72, you must program an AND Group with at least
two smoke detectors and a minimum activation count of 2. The smoke detectors
must have their Primary and Alternate Verification properties set to None (verified
smoke detectors are not allowed).
1. Click the AND Groups tab, and then click Add AND Group.
2. Set the Activation Count box for 2.
3. Click the Members tab, and then click Add Device.
4. Select only the detectors required to activate the GSA-REL release circuits
then click OK.
5. Click the Responses tab, click the Response Type arrow, and then select
Active.
6. Click Delays.
7. In the Delay On list, click Activation and Restoration.
8. Set the Seconds box to 10.
9. Click Outputs, select the device labeled GSA-REL1 A003 RELEASE 1 & 2,
and then click OK.
Step 7: Create a manual release response
In this step, you create a manual release response that activates the release
circuits when someone presses the manual release switch. Add the prerelease
response, create the delay, and then add the release response in that order.
1. Click the Devices tab, and then select the circuit labeled GSA-REL A002
MAN RELEASE.
