Intelligent initiating devices
VM
Notification Appliances
SERIES
Genesis GL Series Wall Models
LED Strobes
Genesis GL Series horns and LED strobes break the current draw barrier with
innovative technology that not only makes them inexpensive to install and oper-
ate, but also allows them to maintain the sleek low-profile design that has made
Genesis appliances a favorite among facility owners, architects, and designers.
Horn-Strobe models feature field-selectable 15, 30, 75, or 110 cd output set-
tings. Horn-strobe and horn-only appliances feature field-configurable high/low
dB and temporal/steady audible output.
White housing White housing Red housing Red housing All fire alarm appliances come
no marking with “FIRE” no marking with “FIRE” with the “Running Man” Icon
GL1WN-HDVMC GL1WF-HDVMC GL1RN-HDVMC GL1RF-HDVMC Horn-Strobe
GL1WN-HD GL1WF-HD GL1RN-HD GL1RF-HD Horn-only
GL1WN-VMC GL1WF-VMC GL1RN-VMC GL1RF-VMC Strobe-only
GL1WN-TP (white) GL1RN-TP (red) Trim Plate for four-inch square boxes
GL1WN-BB1G (white) GL1RN-BB1G (red) One-gang surface box
Genesis WG4 Series Wall Models
Weatherproof Horns
and Horn-Strobes
Genesis WG4 Series horns and horn-strobes are among the most versatile emer-
gency signals of their kind. Rated for indoor or outdoor use, they are suitable for a
wide range of wet and harsh environments with a listed operating temperature range
of as low as -31°F to as high as 151°F (-35°C to 66°C).
Refer to Data Sheet FX85001-0628 -- Genesis Outdoor Horns and Strobes for details.
Field Configuration
Genesis WG4 strobes feature four selectable light output set-
tings. Cd selections are changed by removing the cover and
simply sliding the switches to the desired setting, which remains
visible through a small window on the front of the device after the
cover is replaced. Genesis Horn-strobes may also be
configured for high or low dB output and temporal flash. This
battery-saving feature is intended for private mode signaling only.
White housing White housing Red housing Red housing Outdoor Fire Alarm Appliances
no marking with “FIRE” no marking with “FIRE”
WG4WN-H WG4WF-H WG4RN-H WG4RF-H Horn Only
WG4WN-HVMC WG4WF-HVMC WG4RN-HVMC WG4RF-HVMC Horn-Strobe, standard cd output
WG4WN-HVMHC WG4WF-HVMHC WG4RN-HVMHC WG4RF-HVMHC Horn Only, high cd output
WG4 Mounting Accessories
WG4WTS (white) WG4RTS (red) Surface Skirt for Genesis WG4 Appliances
74347U (white) 449 (red) Surface mount box, outdoor rated
WG4GSKT Genesis WG4 Full Body Mounting Gasket for Smooth Surfaces
Signal In —
Signal In +
Signal Out —
Signal Out +
—/+ designations indicate the signal polarity
required to activate the device.
