Intelligent initiating devices
VM
Notification Appliances
SERIES
Fire Alarm Bells
Kidde fire alarm bells are of the underdome type with heavy-duty mechanisms. Gongs are
made of selected alloy steel to generate the loud, resonant tones. For weatherproof applica-
tion, optional surface weatherproof backboxes are available.
323D-10AW (Grey) 323D-10AW-R (Red) 10-inch Single Stroke, Diode — 20-24Vdc Data Sheet E85001-0333
439D-6AW (Grey) 439D-6AW-R (Red) 6-inch Vibrating, Diode — 20-24Vdc Data Sheet E85001-0333
439D-10AW (Grey) 439D-10AW-R (Red) 10-inch Vibrating, Diode — 20-24Vdc Data Sheet E85001-0333
Multiple Tone Signal
The 5530MD-24AW is a weatherproof heavy-duty industrial, tone-selectable, signaling de-
vice capable of producing volume-controlled, high-decibel tones. It uses a microprocessor
circuit to create 27 distinctive tones. A single tone may be selected by setting a miniature
dip switch within the unit.
5530MD-24AW 27-Tone Selectable Signal — 24Vdc Data Sheet K85001-0415
Multi-purpose Loudspeaker
The HPSA15 loudspeaker is a high-efficiency double re-entrant loudspeaker that operates within a
nominal frequency response range of 400-14,000 Hz, and provides audible output of 120 dB (peak
at one meter) at the rated power level. It includes a versatile, three-way, 25/70.7 V line transformer
that meets a variety of distributed system needs. The transformer is adjustable by means of a
convenient seven-position, watts/impedance selection switch.
HPSA15R2570 15-watt loudspeaker, red Data Sheet K85001-0591
HPSA15G2570 15-watt loudspeaker, gray Data Sheet K85001-0591
Audible Signals
Signal Master
The Signal Master is a simple-to-use accessory that adds enhanced fea-
tures to Genesis and Integrity strobes and Horn-Strobes. It is a dual-purpose
module that provides UL 1971 required precision synchronization for con-
nected Integrity and Genesis strobes, and independent control for connected
Genesis Horns over a single pair of wires. Two methods of Horn control are
available: traditional Horn silence; or, normally-closed contact. Both methods
may be used to silence Horns without turning off strobes on the same circuit.
Two models are available. The Genesis “piggyback” model doesn’t require a
separate electrical box. It simply snaps to the back of the first MG1 signal on
the circuit. The remote mount model mounts in a North American 2½ inch (64
mm) deep one-gang box.
MG1M Genesis Signal Master – Snap-on (piggyback) Data Sheet K85001-0545
MG1M-RM Genesis Signal Master – Remote 1-Gang Mount Data Sheet K85001-0545
Snap-on
(piggyback) model
Remote 1-gang
mount model
