95
These methods are reserved for future expansion of the homing mode.
Methods 33 and 34: Homing on the index
Method 35: Homing on the current position
In this method, the current position is taken to be the home position.
Methods -17 and -18: Use the mechanical terminal as reference point
Example 7-11：Using method 7 for homing.
1. Set parameters.
Numberic display
Parameter Name
meaning
Setting Value
d3.01
Din1_Function
000.1: Driver enabled
000.2: Driver error reset
000.4: Operation mode
001.0:Positive limit
000.1
（Driver enabled）
d3.02
Din2_Function
000.2
（Driver error reset）
