Chapter 7 List of Parameters
67
Function
code
Name
Descriptions
Unit
Factory setting
Modif.
Setting
range
output terminal
Y1
2:Frequency detection threshold
(FDT1)
3:Frequency detection threshold
(FDT2)
4:Overload detection signal(OL)
5:Low voltage signal(LU)
6:External fault stop signal(EXT)
7:Frequency high limit(FHL)
8:Frequency low limit(FLL)
9:Zero-speed running
10:Terminal X1(Reserved)
11:Terminal X2(Reserved)
12:PLC running step complete signal
13:PLC running cycle complete
signal
14:Limit of swing frequency
upper/lower limit
15:Drive ready (RDY)
16:Drive fault
17:Switching signal of host
18:Reserved
19:Torque limiting
20:Drive running forward/reverse
Others.Reserved
A6.15
Open circuit
collector output
Y2 function
The same as A6.14
1
1
X
0~50
A6.16
Output functions
of relay R1
The same as A6.14
1
16
X
0~50
A6.17
Output functions
of relay R2
The same as A6.14
1
15
X
0~50
A6.18
Delay of relay
R1
0.1~10.0s
0.1s
0.1
X
1~100
A6.19
Delay of relay
R2
0.1~10.0s
0.1s
0.1
O
1~100
A6.20
Outputterminal’s
positiveandnegati
ve logic
Binary setting:
0:Terminalis enabled if it is
connected toCorrespondingcommon
terminal, and disabled if it is
disconnected.
1:Terminal is disabled if it is
connected tocorresponding common
1
0
O
0~1FH
