System Sizing TQ 174 / 176
In the application of the TQ Series cabinet systems, two important site variables must be taken into account:
Water Temperature
Inlet Water Quality (TDS)
Note: Production rates in gallons per day (GPD)
Note: Production rates in gallons per day (GPD)
Note: Production rates in gallons per day (GPD)
Note: Production rates in gallons per day (GPD)
TQ 174 Production Chart 75 psi feed pressure to atmospheric tank
TDS
500 1000 1500 2000 2500
45
189 169 151 133 116
55
240 214 189 166 142
65
300 267 234 203 174
75
371 328 287 247 209
85
445 391 340 291 245
Temperature
o
F
TQ 176 Production Chart 70 psi feed pressure to atmospheric tank
TDS
500 1000 1500 2000 2500
45
208 190 163 142 121
55
264 233 204 176 149
65
330 290 253 216 181
75
407 356 308 262 217
85
488 425 365 308 255
Temperature
o
F
TQ 174 Production Chart 75 psi feed pressure to a bladder tank
TDS
500 1000 1500 2000 2500
45
168 149 131 113 96
55
213 188 164 141 118
65
267 234 203 172 143
75
330 288 247 209 172
85
395 343 293 245 202
Temperature
o
F
TQ 176 Production Chart 70 psi feed pressure to a Bladder tank
TDS
500 1000 1500 2000 2500
45
183 160 139 118 98
55
232 202 173 146 120
65
290 252 214 179 145
75
358 309 261 216 174
85
430 368 309 254 203
Temperature
o
F
